16G SFP LW 1310nm 20km Transceivers
16G SFP LW 1310nm 20km Transceivers
16G SFP LW 1310nm 20km Transceivers
16G SFP LW 1310nm 20km Transceivers
16G SFP LW 1310nm 20km Transceivers
16G SFP LW 1310nm 20km Transceivers

16G SFP

16G SFP LW 1310nm 20km Transceivers

Ascent Optics’ SFP-16SM31-20C 16G SFP+ transceivers are high performance, cost effective modules supporting data rate of 14.025Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.

Country Of Origin : China

Delivery Time : 1 -3 Days after PO Confirm

Dimensions (LxWxH ) : 57.5*14.3*12.7

Net weight : 0.025kg

Certificate:

Certificate Certificate Certificate Certificate Certificate Certificate Certificate

P/N: SFP-16SM31-20C

Add to Quote
Product Details
Part No. SFP-16SM31-20C Form Factor SFP+
Data Rate 14G/ps Distance 20KM
Wavelength 1310nm Operation Temperature 0 to 70°C (32 to 158°F)
Connector Duplex LC Voltage 3.3V
Cable Type SMF DDM Yes
Transmitter Type 1310nm DFB Receiver Type PIN
TX Power --5.0~-0.5dBm Receiver Sensitivity < -12.0dBm
Protocols MSA Compliant Warranty 3 years
Key Features
Supports up to 14.025Gbps bit rates Hot-pluggable SFP+ footprint 1310nm DFB laser and PIN photodiode, Up to 20km for SMF transmission Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle Compatible with RoHS Single +3.3V power supply Real Time Digital Diagnostic Monitoring Operating case temperature: Standard: 0 to +70°C
Application
4.25/8.5/14.025G Fiber channel
